2in1 Handheld Oscilloscope 2 Channels With Color Screen Scope Digital Multimeter DMM Meter 6000 Counts EM1230

<p>This handheld oscilloscope is aportable waveformmeasurement tool. And one ofbest 2 in 1test tools inoutdoor testing, repairingorteaching.</p><p>When the real time sample rate is 100MSa/s, the bandwidth is 25MHz. </p><p>When the real time sample rate is500MSa/s, the bandwidth is60MHz.</p><p>When the real time sample rate is1GSa/s, the bandwidth is100MHz. </p><p>​(Notice, if you want to test the rate higher than 100MSa/s, you should purchase additional probe)</p>

• This handheld oscilloscope is aportable waveformmeasurement tool. And one ofbest 2 in 1test tools inoutdoor testing, repairingorteaching.
• When the real time sample rate is 100MSa/s, the bandwidth is 25MHz.
• When the real time sample rate is500MSa/s, the bandwidth is60MHz.
• When the real time sample rate is1GSa/s, the bandwidth is100MHz.
• ​(Notice, if you want to test the rate higher than 100MSa/s, you should purchase additional probe)
• Its multimeter part uses a dedicated chip (6000-count), which can provide a higher precision.
• The large capacity lithium battery can ensure at least 6 hours working after fully charged.
• Horizontal
• Bandwidth DC - 25MHz ( -3dB )
• Channel Number 2
• Raise Time 14ns
• Sampling Rate 100MSa/s
• Horizontal Sensitivity 10ns/div - 5s/div
• Horizontal Precision 0.01% + 1 pixel
• Vertical
• Vertical Sensitivity 10mV/div - 500V/div
• Vertical Precision ±(3% + 1 pixel)
• Vertical Resolution 8 bit
• Maximum Allowable Input Voltage CAT II 300V
• Coupling AC, DC
• Input Impedance 1MΩ, ≤20pF
• Trigger
• Trigger Source CHA, CHB, external trigger
• Trigger Mode Normal, Auto, Single
• Trigger Sensitivity ≤1.0 div
• Trigger Slope rising or falling edge of waveform
• Trigger Coupling AC, DC
• Function Range Accuracy
• DC Voltage 600mV/6V/60V/600V/1000V ±(1% + 5 counts )
• AC Voltage 600mV/ 6V/ 60V/ 600V/1000V ±(1.2% + 5 counts )
• DC Current accuracy See the user manual of the current probe. same as DCV ( add current probe
• AC Current during See the user manual of the current probe.
• If the current probe’s output voltage measurement is DC voltage,measurem accuracy is DCV measuremen plus current probe accuracy.
• Resistance 600Ω/6kΩ/60kΩ/600kΩ/6MΩ ±(1.2% + 5 counts )
• 60MΩ ±(2% + 5 counts )
• Capacitance 6nF\600nF\6μF\60μF\600μF\6nF\6mF ±(4% + 5 counts )
• Diode Test Test voltage is about 3V. ±(5% + 10 counts )
• Cursor Measurement time and voltage measurements
• Display 3.5″ TFT LCD, 52mm×70mm, 240 ×320 pixels
• Memory Location locations 10 waveform storage locations and 10 setup storage
• Battery 3.7V lithium battery
• Power Adapter Output: DC 5V/8W
• Operating Environment Temperature: 0°C ~ 40°C Relative Humidity: ≤ 75%
• Storage Environment Temperature: -10°C ~ 50°C Relative Humidity: ≤ 85%
• Operating Altitude 0 ~ 2000m
• Dimensions 212mm × 121mm × 50mm ( for main body only )
• Weight About 700g
